AT-S63 Management Software Menus Interface User’s Guide
Section IV: Port Security 675
The Display Unicast MAC Addresses menu is shown in Figure 245.
The Display Multicast MAC Addresses menu contains the same
selections.
Figure 245. Display Unicast MAC Addresses Menu
Choose one of the following display types.
1 - Display All
This selection displays all dynamic addresses learned on the ports of
the switch and all static addresses that have been assigned to the
ports. An example of a unicast MAC address table is shown in Figure
246.
Figure 246. Display All Menu - Unicast MAC Addresses
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Display Unicast MAC Addresses
1 - Display All
2 - Display Static
3 - Display Dynamic
4 - Display by Port
5 - Display Specified MAC
6 - Display by VLAN ID
7 - Display on Base Ports
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Display All
Page 1
Total Number of MAC Addresses: 121
MAC Address Port VLANID Type
------------------------------------------------------------
01:80:C1:00:02:01
0 0 Static (fixed, non-aging)
00:a0:d2:18:1a:c8 1 1 Dynamic
00:a0:c4:16:3b:80 2 1 Dynamic
00:a0:12:c2:10:c6 3 1 Dynamic
00:a0:c2:09:10:d8 4 1 Dynamic
00:a0:33:43:a1:87 5 1 Dynamic
00:a0:12:a7:14:68 6 1 Dynamic
00:a0:d2:22:15:10 7 1 Dynamic
00:a0:d4:18:a6:89 8 1 Dynamic
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
