Chapter 26: Protected Ports VLANs
632 Section V: VLANs
Deleting a Protected Ports VLAN
All untagged ports in a deleted protected ports VLAN are automatically
returned to the Default_VLAN.
To delete a protected ports VLAN, perform the following procedure:
1. From the Main Menu, type 2 to select VLAN Configuration.
The VLAN Configuration menu is shown in Figure 198 on page 561.
2. From the VLAN Configuration menu, type 4 to select Configure
VLANs.
The Configure VLANs menu is shown in Figure 199 on page 562.
Note
If option 4, Configure VLANs, is not displayed in the menu if the
switch is running a multiple VLAN mode. To change a switch’s
VLAN mode, refer to “Selecting a VLAN Mode” on page 616.
3. From the Configure VLANs menu, type 3 to select Delete VLAN.
The Delete VLAN menu is shown in Figure 227.
Figure 227. Delete VLAN Menu
4. Type 1 to select VLAN ID (VID).
The following prompt is displayed:
Enter new value -> [2 to 4094] ->
5. Enter the VID of the VLAN you want to delete. You can specify only
one VID at a time.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Delete VLAN
1 - VLAN ID (VID) ........
R - Return to Previous Menu
Enter your selection?
