AT-S63 Management Software Menus Interface User’s Guide
Section I: Basic Features 137
The Port Trunking and LACP menu is shown in Figure 37.
Figure 37. Port Trunking and LACP Menu
3. From the Port Trunking and LACP menu, type 1 to select Static Port
Trunking.
The Static Port Trunking menu is shown in Figure 38.
Figure 38. Static Port Trunking Menu
This menu lists the trunks that already exist on the switch.
4. Type C to select Create Trunk.
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Port Trunking and LACP
1 - Static Port Trunking
2 - LACP Configuration
R - Return to Previous Menu
Enter your selection?
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Static Port Trunking
ID Name Ports Method Status
----------------------------------------------------
C - Create Trunk
D - Delete Trunk
M - Modify Trunk
R - Return to Previous Menu
Enter your selection?
