Chapter 16: Quality of Service
320 Section II: Advanced Operations
Managing Traffic Classes
This section contains the following procedures:
ˆ “Creating a Traffic Class,” next
ˆ “Modifying a Traffic Class” on page 324
ˆ “Deleting a Traffic Class” on page 325
ˆ “Displaying Traffic Classes” on page 327
Creating a
Traffic Class
To create a traffic class, perform the following procedure:
1. From the Main Menu, type 7 to select Security and Services.
The Security and Services menu is shown in Figure 82 on page 259.
2. From the Security and Services menu, type 6 to select Quality of
Service.
The Quality of Service (QoS) menu is shown in Figure 108 on page
313.
3. From the Quality of Service (QoS) menu, type 2 to select Traffic Class
Configuration.
The Traffic Class Configuration menu is shown in Figure 115.
Figure 115. Traffic Class Configuration Menu
4. From the Traffic Class Configuration menu, type 1 to select Create
Traffic Class.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Traffic Class Configuration
1 - Create Traffic Class
2 - Modify Traffic Class
3 - Destroy Traffic Class
4 - Show Traffic Classes
R - Return to Previous Menu
Enter your selection?
