Chapter 7: Static and LACP Port Trunks
152 Section I: Basic Features
2. From the Port Configuration menu, type 4 to select Port Trunking and
LACP.
The Port Trunking and LACP menu is shown in Figure 37 on page 137.
3. Type 2 to select LACP Configuration.
The LACP (IEEE 8023ad) Configuration menu is shown in Figure 41
on page 144.
4. To view port status, type 7 to select Show LACP Port Status. To view
aggregator status, type 8 to select Show LACP Aggregator Status.
Figure 45 is an example of the LACP (IEEE 802.3ad) Port Status
menu. The information in this window is for viewing purposes only. For
definitions, refer to the IEEE 802.3ad standard.
Figure 45. LACP (IEEE 802.3ad Port Status Menu
Figure 46 is an example of the LACP (IEEE 802.3ad) Aggregator
Status menu. The information is for viewing purposes only. An
Allied Telesyn Ethernet Switch AT-9400 Series - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
LACP (IEEE 802.3ad) Port Status
Port ............. 01
Aggregator ....... Sales server
ACTOR PARTNER
====================================++++++++===========================
Actor Port ............. 06
Partner Port ......... 00
Selected ............... SELECTED Partner System ....... 00-30-84-00-00-02
Oper Key ............... 0x0050 Oper Key ............ 0x0004
Oper Port Priority .... 0x0006 Oper Port Priority ... 0x0007
Individual ............. NO Individual ........... NO
Synchronized............ YES Synchronized.......... YES
Collecting ............ YES Collecting ........... YES
Distributing ........... YES Distributing ......... NO
Defaulted .............. NO Defaulted ............ NO
Expired ................ NO Expired .............. NO
Actor Churn .......... YES Partner Churn ........ YES
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
