Chapter 16: Quality of Service
336 Section II: Advanced Operations
The Display Policy Details menu is shown in Figure 125.
Figure 125. Display Policy Details Menu
The Display Policy Details menu provides the following information:
Policy ID
The policy ID number.
Description
The policy description.
Remark DSCP
The conditions under which the ingress DSCP value is overwritten.
DSCP value
The replacement value to write into the DSCP (TOS) field of the
packets.
Traffic Class List
The traffic classes assigned to the policy.
Redirect Port
The port to which the classified traffic from the ingress port is
assigned.
Ingress Port List
The ingress ports to which the policy is assigned.
Egress Port
The egress port to which the policy is assigned.
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Display Policy Details
1 - Policy ID ............ 0
2 - Description .......... video
3 - Remark DSCP .......... None
4 - DSCP value ........... 7
5 - Traffic Class List ... 0
6 - Redirect Port ........ 1
7 - Ingress Port List .... 22
8 - Egress Port .......... 3
U - Update Display
R - Return to Previous Menu
Enter your selection?
