Chapter 7: Static and LACP Port Trunks
140 Section I: Basic Features
3. From the Port Trunking and LACP menu, type 1 to select Static Port
Trunking.
The Static Port Trunking menu is shown in Figure 38 on page 137.
4. Type M to select Modify Trunk.
The following prompt is displayed:
Enter Trunk ID: [1 to 6] ->
5. Enter the ID number of the trunk you want to modify.
The Modify Trunk menu is displayed. The menu displays the operating
specifications of the selected trunk. An example is shown in Figure 40.
Figure 40. Modify Trunk Menu
Note
You cannot change a trunk’s ID number.
1 - Trunk ID
Specifies the trunk ID. Enter an ID number for the trunk, from 1 to 6. A
trunk must be assigned a unique ID number. The default value is the
next unused ID number.
2 - Trunk Name
Specifies the trunk name. Enter a name for the trunk. The name can
be up to 16 alphanumeric characters. No spaces or special characters,
such as asterisks and exclamation points, are allowed. Each trunk
must have a unique name.
3 - Trunk Method
Specifies the load distribution method. The possible settings are:
ˆ SRC MAC - Source MAC address
ˆ DST MAC - Destination MAC address
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Modify Trunk
1 - Trunk ID ......... 2
2 - Trunk Name ....... Server11
3 - Trunk Method ..... SRC/DST MAC
4 - Trunk Ports ...... 12-16
M - Modify Trunk
R - Return to Previous Menu
Enter your selection?
