AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 247
15. Enter a list of modules separated by a comma—for example, “system,
stp, ptrunk.”
16. Type C to create the log output you defined.
The switch immediately begins to send events to the sever, if you
enabled the definition when you created it, and adds the new syslog
server definition to the Configure Log Outputs menu. An example of
the menu with a definition is shown in
Figure 78. Configure Log Outputs Menu with Syslog Output Definitions
17. Return to the Main Menu.
Modifying a Log
Output
To modify a log output definition you have already created, perform the
following procedure:
1. From the Main Menu, type 5 to select System Administration.
The System Administration menu is shown in Figure 4 on page 46.
2. From the System Administration menu, type 8 to select Event Log.
The Event Log menu is shown in Figure 72 on page 231.
3. From the Event Log menu, type L to select Configure Log Outputs.
The Configure Log Outputs menu is shown in Figure 76 on page 242.
4. From the Configure Log Outputs menu, type 2 to select Modify Log
Output.
The following prompt is displayed:
Allied Telesyn Ethernet Switch AT-94xx - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Configure Log Outputs
OutputID Type Status Details
------------------------------------------------------
0
Permanent Enabled Wrap on Full
1 Temporary Enabled Wrap on Full
2 Syslog Enabled 149.44.44.44
1 - Create Log Output
2 - Modify Log Output
3 - Delete Log Output
4 - View Log Output Details
R - Return to Previous Menu
Enter your selection?
