Example
c:\> rcli map target -fc_target=5001-4380-025C-C7D8 -ge_port=1
-vpgindex=1 /ip=10.0.0.12
Target 5001-4380-025C-C7D8 successfully mapped to Ethernet port 1
merge csv
The merge csv command collects input from multiple files and combines them into a new csv
file using output from the show io_statistics or show performance commands. You can
import the csv file into a spreadsheet program such as Microsoft Excel. Use the spreadsheet
program to graph usage over time, so that maintenance can be planned for less busy times.
Syntax
merge csv
Keywords
Specifies the folder containing the csv files from which to collect the LUN and port
performance data. -csv_folder=
If this keyword is not used, the command collects data from csv files in the working
directory.
Specifies the name of the output file for the comma separated text. -file=
If this keyword is not used, the command displays the output text on the console.
Example
c:\> rcli merge csv -csv_folder=c:\temp -file=summary.csv
CSV output file summary.csv created successfully
modify fcip_route
The modify fcip_route command modifies an existing FCIP route for this Fibre Channel port.
NOTE: This command fails if there is no FCIP route currently set for this Fibre Channel port.
The router must be capable and licensed for FCIP. To view router capabilities, issue the show
features
command. See “show features” (page 68) .
Syntax
modify fcip_route -fc_port=fc port number
Keywords
Specifies the bandwidth in Mb/s. Enter a number ranging from 1 to 1000, or 0 to
use the maximum available bandwidth. -bandwidth=
The default value is as currently set on the router.
Enables the Ethernet and Fibre Channel ports for the route. Values are: -enable=
•
yes (default)
•
no
•
on
•
off
•
true
•
false
