178 AM456-9007B Rev 02 HP VMA SAN Gateway Installation and User Guide
Organization of the VMA Web Interface
The VMA Web Interface is organized in into five basic areas: the message bar,
menu bar, shortcuts menu, copyright bar, and the control page.
Message Bar
Each page in the VMA Web Interface has a message bar at the top, which shows
the page’s location in the menu tree, various status messages, your user name, and
the Logout and Help buttons.
The message bar also displays informational messages and occasional error
messages, and indicates whether any configuration changes need to be saved. A
Commit Changes button appears only when needed.
Several key controls are displayed in the Message bar:
Figure B.1 Web Interface Organization
Login Status button
Help button
Messages
Error Messages
Commit Changes button
Message Bar
Shortcuts Menu Copyright Bar
Control Page Menu Bar
