QUICK REFERENCE

61

Default Settings

The default factory installed settings can be
recalled at any time by pressing the Default key.

Default

Acquire

Mode: Sample

XY: OFF

Interpolation: Sin(x)/x

Sample rate: 2GSPS

Record Length: Auto

Display

Mode: Vector

Persistence: 240ms

Waveform intensity: 50% Graticule intensity: 50%

Waveform visuals: Gray Graticule: full

Channel

Scale: 100mV/Div

CH1: On

Coupling: DC

Impedance: 1MΩ

Invert: Off

Bandwidth: full

Expand: By ground

Position: 0.00V

Probe: voltage

Probe attenuation: 1x

Deskew: 0s

Cursor

Horizontal cursor: Off

Vertical Cursor: Off

Measure

Source: CH1

Gating: Screen

Display: Off

High-Low: Auto

Statistics: Off

Mean & Std Dev
Samples: 2

Horizontal

Scale: 10us/Div

Position: 0.000s

Math

Source1: CH1

Operator: +

Source2: CH2

Position: 0.00 Div

Unit/Div: 200mV

Math Off

Test

App: Go-NoGo

Trigger

Type: Edge

Source: CH1
