GDS-2000A Series User Manual
12
Main Features
Features  8 inch TFT SVGA display.
 MSO and DSO models available from 70MHz to
300MHz.
 All models feature a real-time sampling rate of
2GSa/s and an equivalent time sampling rate of
100GSa/s.
 Deep memory: 2M points record length.
 Waveform capture rate of 80,000 waveforms per
second.
 Vertical sensitivity: 1mV/div~10V/div.
 Logic Analyzer module (optional): Adds 8 or 16
channel digital inputs and serial bus (I2C, SPI,
UART) and parallel bus triggering.
 DDS Function Generator module (optional).
 Segmented Memory: Optimizes the acquisition
memory to selectively capture only the
important signal details. Up to 2048 successive
waveform segments can be captured with a
time-tag resolution of 8ns. Segmented memory
can be used for both analog and digital
channels.
 Enhanced Search: Allows the scope to search for
a number of different signal events.
 On-screen Help.
 64 MB internal flash disk.
