GDS-2000A Series User Manual

28

Indicates the frequency is

less than 2Hz (lower
frequency limit).

Trigger
Configuration

Trigger source, slope,

voltage, coupling.

Horizontal Status

Horizontal scale,

horizontal position.

For trigger details, see page 144.

Channel Status

Channel 1, DC coupling,
2V/Div.

For channel details, see page 137.
