APPENDIX

255

GTP-250A-2

Applicable to: GDS-2202A & GDS-2204A

Position X10

Attenuation Ratio

10:1

Bandwidth

DC to 250MHz

Rise Time

1.4nS

Input Resistance

10MΩ when used with oscilloscopes
with 1MΩ input.

Input Capacitance

Approximately 17pF

Compensation Range 10 to 35pF

Max. Input Voltage

Position X1

Attenuation Ratio

1:1

Bandwidth

DC to 6MHz

Rise Time

58nS

Input Resistance

1MΩ (Oscilloscope Input)

Input Capacitance

47pF plus oscilloscope capacitance

Max. Input Voltage

300V CAT I, 150V CAT II (DC + peak
AC) derating with frequency.

Safety

EN61010-031 CAT II

GTP-350A-2

Applicable to: GDS-2302A & GDS-2304A

Position X10

Attenuation Ratio

10:1

Bandwidth

DC to 350MHz

Rise Time

1.0nS

Input Resistance

10MΩ when used with oscilloscopes
with 1MΩ input.

Input Capacitance

Approximately 13pF

Compensation Range 10 to 25pF

Max. Input Voltage

Position X1

Attenuation Ratio

1:1

Bandwidth

DC to 6MHz

Rise Time

58nS

Input Resistance

1MΩ (Oscilloscope Input)

Input Capacitance

46pF plus oscilloscope capacitance

Max. Input Voltage

300V CAT I, 150V CAT II (DC + peak
AC) derating with frequency.

Safety

EN61010-031 CAT II

500V CAT I, 300Vrms CAT II derating
with frequency.

500V CAT I, 300Vrms CAT II derating
with frequency.
