background image

GDS-2000A Series User Manual

164

Search Event
Types

Edge, Pulse Width, Pulse Runt, Rise and Fall Times,
Logic*, Bus*
*Requires the Logic Analyzer option.

Panel Operation

1. Press the Search menu key.

Search

2. Press Search from the bottom menu

and turn the Search function on.

3. Press Search Type from the bottom

menu and select the type of search.
The search events are configured in
the same fashion as the trigger
events.

Please see the trigger configuration
settings for details:

Event
Types:


Edge, Pulse Width, Pulse Runt,
Rise/Fall Time, Logic*, Bus*
*Requires the Logic Analyzer option.

4. To set the threshold levels for the

search events (instead of the
trigger level that is used for trigger
events), use the threshold soft-key
from the bottom menu.

Note

The search function can support up to 10,000 events,
however only 1,000 events can be displayed on screen
at once.
