background image

GDS-2000A Series User Manual

162

5. Press Trigger When from the lower

menu.

Then use the side menu to select trigger
conditions.

Condition

Stays High, Stays Low, Either

6. Press Level from the lower bezel to

set the trigger level.

Range

-XXV~XXV

Set to TTL 1.4V

Set to ECL -1.3V

Set to 50%

7. Press Timer from the lower bezel to

set the timer time.

Range

-10ns~10.0S
