Page 123

background image

CONFIGURATION

123

Segment Info

Operation

1. Press Analyze Segments from the

bottom menu.

Note: This key will only be
available in the Stop mode.

2. Press Segments Info.

3. A table showing all general setting information

for the segmented memory acquisitions is
shown on the display.

Info:

Sample rate, Record length,
Horizontal, Vertical
