SAVE/RECALL

195

Save

File Type/Source/Destination

Item

Source

Destination

Panel Setup
(DSxxxx.set)

Front panel
settings

Internal memory: Set1 ~
Set20

File system: Disk, USB

Waveform Data
(DSxxxx.csv)
(DSxxxx.lsf)
(CH1~CH4.lsf,
Ref1~Ref4.lsf,
Math.lsf)*
ALLxxxx.csv

Channel 1 ~ 4

Math operation
result

Reference
waveform Ref1~4

D0~D15

1

All displayed
waveforms

Internal memory:
Reference waveform
Ref1~4, Wave1 ~ Wave20

File system: Disk, USB

Display Image
(DSxxxx.bmp/png)
(Axxx1.bmp/png)**

Display image

File system: Disk, USB

*Stored in ALLXXX directories when All Displayed waveforms are
saved.
**Stored in ALLXXX directories when the Hardcopy key is assigned
to save Waveform, Setup or All.

1

Digital channels. Only applicable with the Logic Analyzer option.
