GDS-2000A Series User Manual

46

Cursor Key

Set cursor positions.

V Cursor

H Cursor

H Unit

Set Cursor

Positions As

100%

Set Cursor

Positions As

100%

S

Hz

%

˚

V Unit

Base

%

Activates menu

item

Activates menu

item

Cursor

Display Key

Set the display properties.

Dot Vector

Persistence

Dot

Vector

Clear

Persistence

100ms~10s

Infinite

VPO Off

Time

Intensity

0%~100%

Waveform Intensity

10%~100%

Graticule Intensity

Waveform

Gray

Color

Graticule

Full

Grid

Cross Hair

Frame

Display

Help Key

Turn help mode On/Off.

Help
