background image

GDS-2000A Series User Manual

206

*Only files in the current file path will be
available, this includes files saved in the
ALLXXX directories.
Allxxxx.csv files cannot be recalled to the
oscilloscope.
Only the “fast CSV” files can be recalled to the
oscilloscope.

6. Press To and select the reference

waveform to recall to.

To

Ref1~4

7. Press Recall Now to recall the

waveform.

USB File Utility

To edit USB flash drive contents
(create/ delete/ rename files and
folders) or to set the file path, press
File Utilities. For details, see page 211.

Recall Setup

Panel Operation

1. (For recalling from an

external USB flash drive)
Connect the drive to the
front or rear panel USB port.

Front

Rear

Host
