GETTING STARTED

17

GDS-2072A/2102A/2202A/2302A Front Panel

CH1

CH2

POSITION

TIME/DIV

POSITION

POSITION

VOLTS/DIV

VOLTS/DIV

Autoset

Menu

50 %

Force-Trig

Select

TRIGGER

HORIZONTAL

VARIABLE

Measure

Cursor

Display

Help

Save/Recall

Utility

Acquire

Single

Run/Stop

LEVEL

Search

Set/Clear

VERTICAL

Test

POWER

2V

Hardcopy

Option

Menu Off

Zoom

CAT

M

16pF

300Vrms MAX.

1

CAT

M

W 16pF

300Vrms MAX.

1

M

R

B

MATH

REF

BUS

Default

Logic Analyzer

GEN 1

GEN 2

CH1

CH2

EXT TRIG

Digital Storage Oscilloscope

GDS-2202A

200 MHz 2 GS/s

Visual Persistence Oscilloscope

W

LCD

Variable knob
and Select key

Autoset, Run/Stop, Single
and Default settings

CH1~CH4
input

Trigger
controls

Function
keys

USB Host port,
Demo and Ground
terminals

Function
Generator
output 1&2

Power
button

Hardcopy key

Option key

Math,
Reference and
Bus keys

Bottom
menu keys

Horizontal
controls

Menu key

Vertical
controls

Logic
Analyzer
input

EXT
trigger

Side menu keys

LCD Display

8” SVGA TFT color LCD. 800 x 600 resolution,
wide angle view display.

Menu Off Key

Menu Off

Use the Menu Off key to hide the
onscreen menu system.

Option Key

Option

The Option key is used to access
any installed options, such the
Logic Analyzer option.
