Trigger Type Menu
Menu Type
Pulse Runt
Rise & Fall
Bus
Logic
Others
Edge
Delay
Pulse Width
Video
Goes to the Edge Trigger menu
Goes to the Pulse Width Trigger
menu
Goes to the Video Trigger menu
Goes to the Pulse Runt Trigger menu
Goes to the Rise and Fall menu
Goes to the Bus menu
Goes to the Logic menu
Trigger Edge Menu
Type
Edge
Source Coupling Slope Level Mode Holdoff
CH1~ CH4
EXT
AC Line
D0~D15
EXT Probe
Volt
Current
DC
AC
-XX~XXV
Set to TTL
1.4V
Set to ECL
-1.3V
Set to 50%
Auto
Normal
10.0ns~
10.0s
Set to
Minimum
EXT Probe
Off
HF
LF
Reject
On
Off
Noise Reject
On
Off
Alternate
1mX ~ 1kX
Attenuation
