67
protection to trip. Press again to save changes. When
the power supply voltage output reaches this limit, the OVP
will trip.
3. Press twice to exit the menu. To disable it, select
OFF.
Configure OCP
Overcurrent protection (OCP) is available to limit the current output
and to protect a connected DUT from an overcurrent condition.
When the power supply trips the OCP, a short beep will sound and
the OCP (OCP1/OCP2 for dual channel models) LED indicator on
the front panel will be lit. The green output light will also disappear
and output will turn OFF (disable) immediately. To clear the OCP trip,
press any key and the OCP (OCP1/OCP2 for dual channel models)
LED indicator will turn OFF. To activate OCP, follow the steps below:
1. Press , then to enter PROTECTION, and press
to select OCP SETTING.
OCP = ON SET = 10.000 A
Esc
Enter
Menu 3 2
