32
3.2 Remote Interface Setup
The standard remote interface available on all models in the series
is the USB (virtual COM) interface. Other optional supported
interfaces such as GPIB, Ethernet (LAN), RS-232, and RS-485are
available, but dependent on the interface card(s) installed on the
instrument. This section will describe how to setup all the supported
interfaces.
Note: The RMT LED will automatically light up when the power
supply is successfully connected to a PC remotely through any
remote interface. Keys on the front panel will be locked until
( LCL) is pressed to set the instrument back to LOCAL mode.
USB Interface (virtual COM)
The USB interface comes standard on every power supply in the
series. A
USB Type A to Type B cable (i.e. USB printer cable) is
required to connect the USB port ( ) in the rear panel to a PC.
Follow the steps below to setup the power supply for USB (virtual
COM) remote communication.
1. Press , then to enter SYSTEM SETTING. Select
REMOTE and verify that it shows USB, which is the default
option. If not, press or until “ USB” is displayed.
Press to save changes.
Menu 1
.
Enter
