38
7. With the connections setup properly, on the first power
supply, press , then to enter SYSTEM SETTING.
Select REMOTE and verify that “USB” is selected. Press
to save changes.
8. Press once to go back to the main menu and press
to enter CHAIN SETTING.
9. Select CHAIN ON/OFF and press or to set it to “ ON”.
Press to save changes.
10. Select CHAIN ADDRESS and set it to “1”. Press to
save changes and then press twice to exit the
menu.
11. Repeat steps 7 thru 10 for each of the power supplies in the
chain. However in step 10, set the CHAIN ADDRESS of
each power supplyto a different number. (i.e. Set to 1 for
power supply #1, 2 for power supply #2, 3 for power supply
#3, …etc.) The address is used to reference the power
supply during remote operation.
12. Refer to “4.2 Remote Commands” for the list of remote
commands specific for RS485 communication.
Menu 1
Enter
Esc 9
Enter
Enter
Esc
