EVS IPDirector Version 6.0 - November 2012 Part 8 User's Manual - Manual (Page 81)

Fields in the Create Timeline Window
Timeline Information Pane
The left pane contains the following fields:
Field Description Mandatory ?
Name Name of the timeline in maximum 32 characters. Yes.
Description Description of the timeline in maximum 256 characters No
LSM ID ID identifying the timeline position in the XNet network.
The timeline can be stored on bank 10 of any page of a
server.
The timeline ID is made up as follows:
/
where:
• The timeline position is between 01 and 99.
• The server number is from 1 to 29.
If you enter a requested position that is already used,
the application will display an error message. You'll
have to enter a new position.
If you do not enter an ID in the Create a New Timeline
window, the Timeline ID is automatically assigned
when IPEDIT creates the timeline.
No
IPDirector - Version 6.00 - User Manual - IPEdit
6. Timeline 69
