Play/Pause Position Indicator Timecode Value Color
Pause On or between IN
and OUT points Count down to the OUT point White
Pause Before IN point Count down to the IN point White
Pause After OUT point Duration from the OUT point Grey
Play On or between IN
and OUT points Count down to the OUT point Yellow
Play Before IN point Count down of the remaining time to the
OUT point White
Play After OUT point Count down of the remaining time to the
end of guardband (Protect OUT point) White
When a Record Train is Loaded
The following table shows the possible colors and meanings of the Remaining Time /
Capacity field when a train is loaded.
The Remaining Time / Capacity field value and color depends on:
• whether the train is playing or paused
• whether an IN and/or OUT points are defined
• the media position indicator.
Play/Pause IN/OUT Point Position Indicator Timecode Value Color
Play No IN, no
OUT On the head of
record train Recording capacity left
on the train Blue
Play/Pause No IN, no
OUT Before the head of
record train Delay time from the
head of record train Yellow
Play/Pause Only IN
defined Before IN point Duration to IN point White
Play/Pause Only IN
defined After IN point Duration from IN point Yellow
Play/Pause Only OUT
defined Before OUT point Duration to OUT point Yellow
Play/Pause Only OUT
defined After OUT point Duration from OUT
point White
Play/Pause IN and OUT
defined Before IN point Duration to IN point White
