Area Description
5. Timeline
Editing
buttons The Insert, Overwrite and Match Frame Replace buttons allow to
perform some editing actions on the timeline, from the Player.
See section "Timeline Editing Buttons" on page 32.
6. Track
Selection The Player Track Selection allows you to select the tracks to be taken
into account when you play the loaded media and when you add the
media to a timeline.
See section "Player Track Selection" on page 34.
7. Audio
Monitoring The Audio Monitoring feature allows you to monitor and adjust the
global audio level that is output when playing the media loaded on the
Player through headphones.
See section "Audio Monitoring" on page 37.
5.2. Video Display
5.2.1. Purpose
The video display makes it possible to view any media loaded on the Player that is
available on the XNet network.
5.2.2. Prerequisites
The video display needs to be connected to the server's PGM2 (or PGM4) SDI output to
be operational. See section "Assigning Player Channels to IPEdit" on page 6 for more
information.
5.2.3. Activation and Deactivation
When the video display is operational, you can activate or deactivate it by right-clicking
the Video Display area and selecting Show/Hide Video Display.
5.2.4. How to Associate a Video Display to the
Player
Prerequisite
In all cases, the video display will only be available in the Player if the PGM2 or PGM4 of
the server is physically connected to the IPDirector workstation on which the AVH board
is installed.
