Result
The automatic swap action performed generates the following swaps on the output audio
channels of the timeline element:
The source channels are sent to the output channels of the timeline element …
a1 (on G1) a3 (on G2)
a2 (on G1) a4 (on G2)
a3 (on G2) a5 (on G3)
a4 (on G2) a6 (on G3)
a5 (on G3) a7 (on G4)
a6 (on G3) a8 (on G4)
a7 (on G4) are muted
a8 (on G4) are muted
Note
If you position the mouse on the G3 track, the a1 source channel is sent to the a5
output channel, and so on. In this situation, the channels of the source tracks G3
and G4 are muted in the timeline.
6.13.4. Automatic Mute Definition
Description
When you mute one, more or all channels of a track on the source media loaded on the
Player, these channels or tracks will be muted once the source media is added to the
timeline.
