NT5D12 Dual-port DTI/PRI 69
Figure 27
NTCK46AA, NTCK46AB, NTCK46AC, NTCK46AD
External MSDL cable
The NTCK80 cable connects the DDP card to the NT6D80 MSDL card. The
cable is available in four different sizes:
• NTCK80AA (6 ft.) - DDP to MSDL cable
• NTCK80AB (18 ft.) - DDP to MSDL cable
• NTCK80AC (35 ft.) - DDP to MSDL cable
• NTCK80AD (50 ft.) - DDP to MSDL cable
Figure 28
NTCK80AA, NTCK80AB, NTCK80AC, NTCK80AD
Cable diagrams
Figure 29 "DDP cable for systems with an I/O panel" (page 70) provides an
example of a typical cabling configuration for the DDP. Please note that
these figures are representational only, and are not intended to show the
relational card slot position of the various cards.
Figure 29 "DDP cable for systems with an I/O panel" (page 70) shows
a typical DDP cabling for a system Option with an I/O panel, with the
connection between the I/O panel and a Network Channel Terminating
Equipment (NCTE).
