118 NT8D72 and QPC720 PRI card installation
Cable From Des. Con. To Des. Con. Comments
QCAD124
NT8D85xx QPC720 J3 Network Run directly to
network card.
QCAD328A QPC720 J5 QPC757 J2 Run directly to
DCHI card.
NTND26 QPC720 J5 NT6D80
QCAD133 I/O Panel Patch panel Run via cabinet
I/O panel to
CSU, Echo
Canceller, or
cross connect
terminal.
QCAD129 QPC720 J6 I/O Panel
RS-232 I/O Panel Echo Canc
eller
RS-232 QPC720 J6 Echo Canc
eller
QCAD133
NT8D83xx QPC720 J4 Patch panel Run via cabinet
I/O panel to
crossconnect
terminal or Echo
Canceller from
non-shielded
system.
Table 32
Cable for the QPC720 PRI card on Multi Group systems
Cable From Des. Con. To Des. Con. Notes
QCAD130
NT8D79xx QPC720 J1 QPC47
1
QCP77
5 CC-0 Only when
primary clock
source
QCAD130
NT8D79xx QPC720 J1 QPC47
1
QCP77
5 CC-0 Only when
secondary clock
source
QCAD130
NT8D79xx QPC720 J2 QPC47
1
QCP77
5 CC-1 Only when
primary clock
source
