Page 300
300
Nonstandard cables
Color
From
(pack end)
To
(I/O end)
Signal
Black
P1-7
P2-7
XRING (transmit)
Green Shield
P1-9
nc
GROUND
Red
P1-2
P2-2
RTIP (receive)
Black
P1-3
P2-3
RRING (receive)
Red Shield
P1-5
nc
GROUND
QCAD328
This cable is used to connect the PRI pack to the D-channel interface card,
either the QPC757 or NT6D11AB DCHI. There are two types of QCAD328
cables: QCAD328A and QCAD328B.
•
QCAD328A - 1.8 m (6 ft)
•
QCAD328B - 5.5 m (18 ft)
•
QCAD328C - 10.67 m (35 ft)
•
QCAD328D - 15.24 m (50 ft)
•
Construction - 24 AWG (0.511 mm), stranded
•
P1 Connector - 25-pin male, subminiature D
•
P2 Connector - 15-pin male, subminiature D
Table 113
QCAD328 wire list
From
To
Signal
P1-2
P2-2
SDA+
P1-13
P2-10
SDB-
P1-20
P2-15
TR
P1-15
P2-9
STA+
P1-14
P2-11
STB-
P1-3
P2-4
RDA+
P1-16
P2-12
RDB-
P1-17
P2-5
RTA+
P1-12
P2-13
RTB-
P1-8
P2-8
RR
P1-5
P1-8
CS
P1-7
P1-1
SG
P1-1
P2-1
GND
Nortel Communication Server 1000
ISDN Primary Rate Interface Installation and Commissioning
NN43001-301
02.03
Standard
Release 5.5
7 December 2007
Copyright © 2003-2007, Nortel Networks
.
