246 2.0 Mb DTI implementation
Prompt Response Description
TIME 64-(128)-192 Length of BURS(R) pulse in milliseconds.
N If SEZV(S) not required.
P CAS(R) abcd CAS Flash. Same timing as analogue trunks. Prompted for
JDMI only. Operational only if CASR package equipped.
N If CAS(R) not required.
CLRB(R) abcd Clear back.
N If CLRB(R) not required, when IDLE is used.
P RCTL(R) abcd Release control. Prompted only when CLRB is unused or is
defined the same as IDLE.
N If RCTL(R) not required.
TIME 96-(128)-320
96-(256)-320 Time value stored in multiples of 8 milliseconds.
P NXFR(R) abcd Network transfer.
N If not required.
P ESNW(R) abcd ESN wink signal.
N If ESNW(R) not required.
P CAS(R) abcd Centralized attendant service signal.
2.0 Mb DTI only
3 .
N If CAS(R) not required.
CLRF(S) abcd Clear forward (send).
N If CLRF(S) not required.
TIME (0) 800 milliseconds.
Note: Prompted when the abcd bits entered in response to the
CLFR(S) prompt are different from the abcd bits of the IDLE
signal.
SOSO abcd (N) Special operator signal defined (undefined).
Note: Prompted when OPRC = N.
LD 73 - Defining the 2.0 Mb DTI pad tables
Prompt Response Description
REQ NEW
CHG Add or change Digital Trunk Interface data block.
TYPE DTI2 2.0 Mb DTI.
FEAT PAD Request the digital pad feature.
