Description 159
In an isolated private network, the clock controller can operate in free run
mode and act as a master clock to be tracked by other PBX systems in
the private network.
Hierarchical synchronization
Figure 59 "Hierarchical Synchronization" (page 159) provides a general
view of the Digital Network Clock Synchronization including the four stratum
level Node Categories. Stratum 1 being the most accurate and Stratum 4
being the least accurate. System clocking meets Node Category E Stratum
4 requirements. Also shown are ways of providing a Secondary Clock
Source while preventing timing loops.
Figure 59
Hierarchical Synchronization
