Page 138: Table 52 "ntbk51aa dch
138
NT5D97 Dual-port DTI2/PRI2 installation and removal
Table 52
NTBK51AA DCH switches for NT5D97AD
Switch number
Function
S9_1-4
DCH daughter card address
S9_5-8
Set to OFF
S9_9
Set to ON (NTBK51AA Mode)
S9_10
Set to ON (NTBK51AA Mode)
MSDL external card
Table 53 "Switch settings for MSDL external card" (page 138)
lists the switch
numbers assigned for future use on the MSDL external card.
Table 53
Switch settings for MSDL external card
Switch number
Function
S9_1-10
For future use
S8_1-10
For future use
Use
Table 54 "Switch setting for MSDL external card" (page 138)
to set
the card address.
Table 54
Switch setting for MSDL external card
Switch Setting
DNUM (LD 17)
1
2
3
4
0
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
3
ON
ON
OFF
OFF
4
OFF
OFF
ON
OFF
5
ON
OFF
ON
OFF
6
OFF
ON
ON
OFF
7
ON
ON
ON
OFF
8
OFF
OFF
OFF
ON
9
ON
OFF
OFF
ON
10
OFF
ON
OFF
ON
11
ON
ON
OFF
ON
12
OFF
OFF
ON
ON
