NT5D97 Dual-port DTI2/PRI2 card
37
Function
Faceplate
Designator
Type
Description
Unit 0 Clock 0
RJ11 Connector
Connects reference
clock 0 to Clock
Controller card 0
Unit 0 Clock 1
RJ11 Connector
Connects reference
clock 0 to Clock
Controller card 1
Unit 1 Clock 0
RJ11 Connector
Connects reference
clock 1 to Clock
Controller card 0
Unit 1 Clock 1
RJ11 Connector
Connects reference
clock 1 to Clock
Controller card 1
J5 TRK
9 Pin
Female D Connector
Two external E1 Trunk
0 and Trunk 1
Connectors
J6 DCH
26 Pin
Female D Connector
Connects to external
DCH or MSDL
ENET
2 Red LEDs
ENET 0 or ENET 1 is
disabled
DIS
2 Red LEDs
Trunk 0 or Trunk 1 is
disabled
OOS
2 Yellow LEDs
Trunk is out of service
NEA
2 Yellow LEDs
Local (Near End) Alarm
FEA
2 Yellow LEDs
Far End Alarm
LBK
2 Yellow LEDs
Loop Back test being
performed on Trunk 0
or Trunk 1
LEDs
DCH
Bicolor Red/Green LED
NTBK51AA status
The following is a brief description of each element on the faceplate.
Enable/Disable Switch
This switch is used to disable the card prior to insertion or removal from
the network shelf. While this switch is in disable position, the card will not
respond to the system CPU.
ENET LEDs
Two red LEDs indicate if the "ENET0" and "ENET1" portions of the card are
disabled. These LEDs are lit in the following cases:
•
When the enable/disable switch is in disabled state (lit by hardware).
•
After power-up, before the card is enabled.
