R1-SW24L2B User’s Manual
4-12
Connecting a Console Terminal
Connect the PC or terminal to the console port on the Corecess R1-SW24L2B using the console
cable included with the Corecess R1-SW24L2B.
Console cable (RJ-45 - DB-9)
y
Console cable included with the system
y
Max. cable length : 15m
Console Terminal
R1-SW24L2B
