R1-SW24L2B User’s Manual
A-2
Hardware Specifications
Table A-1 Corecess R1-SW24L2B hardware specifications
Switching Fabric
y Switching throughput : 8.8Gbps full-duplex
y Performance : 13Mpps (64 byte packets)
y MAC address : Maximum 8K (Layer 2)
Memory
y Main memory : 64MB (SDRAM)
y Flash memory : 64MB
System Dimension and Weight
y Size : 440 x 44 x 220mm (W x H x D)
AC Power Supply
Hardware
y Frequency : 50/60Hz
y Input Voltage : 100 ~ 240VAC
y Input Voltage Range : 88 ~ 264VAC
Temperature
y Operating Range : -20 ~ 60°C
y Storage Range : -30 ~ 75°C
Humidity
Operational
Environment
y Operating Range : 10 ~ 95% (40°C, non-condensing)
Rack Installation Kit
y Four binder-head screws
Cables
y Console Cable (RJ-45 – DB-9)
Manual
Packages
y User Reference Manual
