R1-SW24L2B User’s Manual
9-26
Configuring Packet Filtering
In a policy-map, you can add criteria for filtering a traffic class or forwarding it to the internal
system processor.
To add a criterion for deciding whether filtering packets or forwarding, perform this task in the
Global configuration mode.
Table 9-5 Configuring packet filtering of a traffic class in a policy map
Command Task
qos 1. Enter QoS configuration mode.
policy-map
map-name>
2. Create a policy map and enter policy-map configuration mode.
y : The name of a policy-map.
class
3. Specify the class to which the policy map applies and enter policy-map-
class configuration mode.
y
: The name of the class to which the policy map applies.
filter {deny|
permit |to-proc}
4. Select the filtering method of the traffic class.
y deny: Discard the traffic.
y permit: Forward the traffic.
y to-proc: Send the traffic to the CPU.
This example configure to discard the traffic class
class2 in the policy map policy1 :
(config)# qos
(config-qos)# policy-map policy1
(config-pmap)# class class2
(config-pmap-c)# filter deny
(config-pmap-c)#
