R1-SW24L2B User’s Manual
2-4
Fast Ethernet Port LEDs
The Fast Ethernet port LEDs (LINK/ACT) indicates the data transmission/reception status and
connection speed of each port.
The LINK/ACT LED display the information on the port connection and data transmission as
follows:
Table 2-2 LNK/ACT port status LED descriptions
LED Color Status Description
On The port is enabled and connecting to the devices.
Flashing Data is being transmitted/received through the port. LINK/ACT Green
Off The port is disabled or not connecting to the device.
Fast Ethernet Port (1 ~ 24)
The Corecess R1-SW24L2B provides 24 Fast Ethernet downlink ports. The specification of the
Fast Ethernet ports is as follows:
Table 2-3 Fast Ethernet port specification
Item Specification
Interface 10/100Base-TX
Trasmission Speed 10/100Mbps
Transmission Mode Full-duplex or half duplex (Auto sensing)
Connector Type RJ-45
Port Number 24
Maximum Cable Length 100m
Transmission Media Twisted-pair category-3, 4, 5 cable
