Hardware
2-5
Option Modules
There is an option slot on the front panel of the Corecess R1-SW24L2B and you can install the
following option modules into it.
Table 2-4 Types of option modules
Option Module Description
OPT-N1ES1CD
1 port, 10/100/1000Base-TX (RJ-45)
1 port, 100/1000Base-LX/SX SFP (Duplex LC) support 100M/1000M
1 port, 1000Base-PX SFP (Maximum cable length: 10Km)
OPT-N1EL1CD
1 port, 10/100/1000Base-TX (RJ-45)
1 port, 100/1000Base-LX/SX SFP (Duplex LC) support 100M/1000M
1 port, 1000Base-PX SFP (Maximum cable length: 20Km)
OPT-N2CD
2 port, 10/100/1000Base-TX (RJ-45)
2 port, 100/1000Base-LX/SX SFP (Duplex LC) support 100M/1000M
OPT-N2CS
2 port, 10/100/1000Base-TX (RJ-45)
2 port, 1000Base-LX/SX SFP (Duplex LC) support 1000M
This section describes the types and functions of option module that can be installed in the
option slot of the Corecess R1-SW24L2B.
