Configuring the Path Cost
When spanning tree is configured, if there are over two paths, lower cost of the path is selected.
By default, path cost of a port is decided by physical link speed as follows:
y Ethernet link (10Mbps): 2,000,000
y Fast Ethernet link (100Mbps): 2000,000
y Gigabit Ethernet link (1Gbps): 20,000
If you want to rarely use a port that is high speed because of a lack of stability or other reasons,
you specify high path cost of the port.
To configure the path cost for the specified port, use the following commands.
Table 13-12 Configuring the path cost
Command Task
configure terminal 1. Enter Global configuration mode.
port
/
pathcost
2. Set the path cost for a specific port..
y : The type of Ethernet port.
- fastethernet
: Fast Ethernet port
- gigabitethernet
: Gigabit Ethernet port
y / slot/port number of a port
y path cost of a port (1 ~ 200000000).
end 3. Return to Privileged mode.
show stp port
type> /
4. Verify the configuration result.
The following example shows how to set the path cost for the Fast Ethernet port 2/1 to 20000:
(config)# port fastethernet 2/1 pathcost 20000
(config)# end
# show stp port fastethernet 2/1
Link State: up
Protocol Operation: enabled
Pathcost Encoding: 32bit
Port Number(logical): 129
Port Priority: 0x8
Designated Path Cost: 20000
AdminEdge: false
