Configuring STP/RSTP
13-21
Configuring RSTP
This section describes how to configure RSTP on the Corecess R1-SW24L2B.
Configuration Procedure of RSTP
The following procedure describes how to configure RSTP.
y Enabling RSTP on a VLAN
y Enable STP on a port
y Setting the bridge ID
y Configuring the path cost
y Configuring STP encoding
y Configuring the port priority
y Setting spanning tree timers (Hello time, Max age, Forward delay)
y Configuring spanning tree protocol type
y Configuring edge port
In the configuration procedure, ‘
Enable STP on a port ’, ‘ Setting the bridge ID ’, ‘ Configuring the port
priority ’ and ‘ Setting spanning tree timers (Hello time, Max age, Forward delay) ’ are explained in the
previous section.
