This example designates 25% for the bandwidth ratio of the transmission queue for the traffic
class class2 in the policy map class policy1 :
(config)# qos
(config-qos)# policy-map policy1
(config-pmap)# class class2
(config-pmap-c)# weight 25
(config-pmap-c)#
Configuring Policy-Map Class Priority
The priority command in the policy-map configuration mode can assign the user-defined
priority to a traffic class. This user-defined priority is used for selecting one of eight
transmission queues in an output port for buffering packets. It is also used as the value for CoS
field. By default, a transmission queue is select by this user-defined priority. However, you can
use the CoS, DSCP, or VLAN ID when selecting a transmission queue. To do this, use the
queue-precedence
command in the QoS configuration mode.
The following is a procedure for specifying the user-defined priority for a traffic class:
Table 9-7 Specifying a priority of a traffic class in a policy map
Command Task
qos
1. Enter QoS configuration mode.
policy-map 2. Create a policy map and enter policy-map configuration mode.
y : The name of a policy-map.
class
3. Specify the class to which the policy map applies and enter policy-map-
class configuration mode.
y
: The name of the class to which the policy map applies.
priority
4. Gives priority to a class of traffic belonging to a policy-map.
y : Priority (0 ~ 7). ‘0’ is the highest priority queue and ‘7’ is the
lowest priority queue .
This example assigns the queue with the priority of 7 to the traffic class
class4 in the policy map
policy1 :
(config)# qos
(config-qos)# policy-map policy1
(config-pmap)# class class4
(config-pmap-c)# priority 7
(config-pmap-c)#
