R1-SW24L2B User’s Manual
5-42
Upgrading Software
You can download the software for the cards on the Corecess R1-SW24L2B from a remote TFTP
server. To download software from a TFTP server, the Corecess R1-SW24L2B should be
connected with remote source server as follows:
To download software from a remote TFTP server to the Corecess R1-SW24L2B, perform this
task in Privileged mode:
Table 5-28 Downloading software from a remote TFTP server
Command Task
copy tftp flash
1. Download specified file from the TFTP server.
y : IP address of the TFTP server.
y image: Downloads system image file from the TFTP server.
y : The file name used for saving the downloaded
file.
show flash image
2. Verify software download.
update flash image
3. Select an image used for booting code.
y : Id of the image.
reset system
4. Reboot the system.
Source server
Network
Remote telnet
Console
Corecess R1-SW24L2B
