Connector Specifications
RJ-45 Connector
10/100/1000Base-T Port
10/100/1000Base-T ports
on the
uplink modules
have the 8-pin RJ-45 connector. The
cable used for connecting 10/100/1000Base-T port is twisted-pair cable with RJ-45
connectors at both ends.
Pin configuration of 10/100/1000Base-T port is as follows:
Table B-1 Pin Configuration of 10/100/1000Base-T Port
Pin Signal Pin Signal
1 Tx, Rx+ (1 pair) 5 Tx, Rx+ (3 pair)
2 Tx, Rx- (1 pair) 6 Tx, Rx- (2 pair)
3 Tx, Rx+ (2 pair) 7 Tx, Rx+ (4 pair)
4 Tx, Rx- (3 pair) 8 Tx, Rx- (4 pair)
Console Port
The CONSOLE port on the front panel of the Corecess R1-SW24L2B has an 8-pin RJ-45
connector. The cable used for connecting console port is serial cable with an RJ-45
connector and a DB-9 at each end.
Pin configuration of Console port is as follows:
Table B-2 Pin Configuration of Console Port
Pin Signal
2 Tx
3 Rx
5 GND
