Page 23: Two option slots
Overview
1-3
Hardware Features
Switching and Routing Performence
y
Provides the high performance switching fabric of 8.8Gbps@Full-duplex.
y
Provides the packet processing performance of 13Mpps@64byte.
Memory
y
Main Memory (Protocol processing)
: 64Mbytes
y
Flash Memory
: 64Mbytes
y
Packet Buffer
: 32Mbytes
Interface
The Corecess R1-SW24L2B supports the following interfaces:
y
Various type of uplink interface
y
Fast Ethernet downlink interface (10/100Base-TX)
y
Local management interface (Console, RJ-45)
y
Remote management interface (Ethernet, RJ-45)
Two Option Slots
The Corecess R1-SW24L2B provides one option slot in which a variety of option modules can be
installed as follows:
Table 1-1 Types of Uplink module
Uplink Module
Specification
OPT-N1ES1CD
1 port of 10/100/1000Base-TX (RJ-45)
1 port of 100/1000Base-LX/SX SFP (Duplex LC)
1 port of 1000Base-PX SFP – Maximum cable length of 10Km
OPT-N1EL1CD
1 port of 10/100/1000Base-TX (RJ-45)
1 port of 100/1000Base-LX/SX SFP (Duplex LC)
1 port of 1000Base-PX SFP – Maximum cable length of 20Km
OPT-N2CD
2 port of 10/100/1000Base-TX (RJ-45)
2 port of 100/1000Base-LX/SX SFP (Duplex LC) supported 100M/1000M
OPT-N2CS
2 port of 10/100/1000Base-TX (RJ-45)
2 port of 1000Base-LX/SX SFP (Duplex LC) supported 1000M
