R1-SW24L2B User’s Manual
8-8
Configuring Community Strings
You use the SNMP community string to define the relationship between the SNMP manager
and the agent. The community string acts like a password to permit access to the agent on the
system. One thing to be aware of is that in case of adding new community string using the
Corecess R1-SW24L2B CLI command, this community string must be added in NMS in order to
connect to the system using this community string. To define SNMP community strings, use the
following commands in Privileged mode:
Table 8-4 Configuring SNMP community strings
Command Task
configure terminal
1. Enter Global configuration mode.
snmp-server community
2. Define the SNMP community strings for each access type.
y : The SNMP community name for this
system. Enter an unquoted text string with no space and a
maximum length of 12 characters.
y : Access type for this community (read-only, read-write)
end
3. Return to Privileged mode.
show snmp-server 4. Verify new community string.
The following example defines new community string:
# configure terminal
(config)# snmp-server community R1SW24 rw
(config)# end
# show snmp-server
RMON: Enabled
Extended RMON: Extended RMON module is not present
sysContact Dial Operator at phone
sysLocation 1st_floor_lab
Community-Access Community-String
---------------- ----------------
read-write R1SW24
:
:
