Basic Configuration
5-43
The following is an example of downloading ‘ r1sw24l2-base-osapp-kt_0.0.6.img ’ file from the TFTP
server whose IP address is 172.27.2.17 :
# copy tftp 172.27.2.17 flash image r1sw24l2-base-osapp-kt_0.0.6.img
tftp: data 10000 Kbytes
# show flash image
System flash directory:
File Length (bytes) Name/status
----- --------------- ------------------------------------------
1 10352627 r1sw24l2-base-osapp-1.0.13.img
2 10331844 r1sw24l2-base-osapp-hphong_0.0.1.img (*)
3 10190924 r1sw24l2-base-osapp-kt_0.0.6.img
[30154 blocks used, 21040 available, 51194 total, 1K-blocks]
*/# : running/updated image
# update flash image id 3
# reset system
halt system now
Restarting system.
..
