Page 167
157
SMC–4000 User Manual
MF (Motion Forward)
[Trippoint]
DESCRIPTION:
The MF command is a trippoint used to control the timing of events. This command will hold up the
execution of the following command until the specified motor moves forward and crosses the position
specified. The units of the command are in quadrature counts. The MF command can also be used when the
encoder is the master and not under servo control, because the actual position is monitored.
ARGUMENTS: MFx, y, z, w or MFX=x or MFa ,b, c, d where
x, y z, w, or a, b, c, d are signed integers
USAGE:
RELATED COMMANDS:
EXAMPLES:
HINT:
The accuracy of the MF command is the number of counts that occur in 2 msec. Multiply the speed by 2 msec to
obtain the maximum error. MF tests for absolute position. The MF command can also be used when the specified
motor is driven independently by an external device.
While Moving
Yes
Minimum Value
-2147483648
In a Program
Yes
Maximum Value
2147483647
Command Line
Yes
Default Value
---
Can be Interrogated
No
Default Format
---
Used as an Operand
No
Virtual Axis
No
#TEST Program
B
DP0 Define
zero
JG 1000
Jog mode (speed of 1000 counts/sec)
BG
Begin move
MF 2000
After passing the position 2000
V1=_TP Assign
V1
position
MG "Position is", V1= ST
Print Message Stop
EN
End of Program
